Tank Cleaning Machines

Model: S-15                             Click Here For Printable Version : In Adobe Acrobat Format

                                                                  If you do not have the Acrobat Reader, it is available free of charge by clicking on the icon and following the download instructions.

General Specifications:

Bore 1.50" (inch)
Type RJH
Standard Connections 1.50" NPS(M); 1.50" BSP(M); 1.50" ANSI 150# Flat Faced Flange
Number of Nozzles 2 or 4
Nozzle Orifice (mm) 6,7,8,9,10,11,12
